Dough Mixers
53 liter Spiral Dough Kneader, 2 Speeds

Two speed kneading for faster cycles (tool speed: 80 and 160 rpm; bowl speed: 10 and 20 rpm).

Two speed kneading for faster cycles (tool speed: 80 and 160 rpm; bowl speed: 10 and 20 rpm).

Stainless steel (AISI304) squared dough breaker bar for fast and even kneading results

Minimum keading capacity: 23 kg per cycle, with 60% hydratation.

Stainless steel (AISI304) squared dough breaker bar for fast and even kneading results

Central column for optimal kneading.

Minimum keading capacity: 23 kg per cycle, with 60% hydratation.

Transparent protective screen to reduce flour dust release in the work area during kneading (EU EN453:2014) and to prevent dough contaminations.

Transparent protective screen to reduce flour dust release in the work area during kneading (EU EN453:2014) and to prevent dough contaminations.

Maximum kneading capacity 42 kg per cycle (max. flour 26.3 kg/cycle), with 60% hydration.

Safety device stops the appliance if the cover is openend.

Safety device stops the appliance if the cover is openend.

Equipped with 4 wheels, of which 2 with brakes, allowing to easily move the appliance for storage or cleaning.

Equipped with 4 wheels, of which 2 with brakes, allowing to easily move the appliance for storage or cleaning.

The appliance fits under standard kitchen worktops (see installation drawing).

The appliance fits under standard kitchen worktops (see installation drawing).

Central column for optimal kneading.

Constructed in painted steel.

Constructed in painted steel.

AISI304 stainless steel bowl, spiral hook and dough breaker bar.

AISI304 stainless steel bowl, spiral hook and dough breaker bar.

Control panel with on/off switch, speed selection and timer.

Power: 1100 watts.

Control panel with on/off switch, speed selection and timer.

Analogic timer up to 30 minutes or continous mode.

Analogic timer up to 30 minutes or continous mode.

IP54 protected control panel.

IP23 for the appliance overall.

IP23 for the appliance overall.

Power: 1100 watts.

Capacity:

Maximum kneading (60% hydratation): 42 kg/Cycle

Electric

Supply voltage: 380-415V/3 ph/50 Hz

Total Watts: 2.2 kW

Key Information:

External dimensions, Width: 560 mm

External dimensions, Depth: 880 mm

External dimensions, Height: 830 mm

Shipping weight: 118 kg

Bowl capacity: 53 lt
